Manual Objectives

This manual has been written to provide the users of MATRIX CUBE (MCC) system with the essential information
required to:

Correctly install and connect the various system components (creel items, MATRIX TOUCH DIAPER terminal, SM-
DIN/MULTILOOP control Board, DIAPER FEEDER devices, TMS sensors, etc.)

Configure the system according to the application needs and setup the various operation parameters.

Load/replace the yarn spools inside the creel modules and correctly carry out the junction of yarns between the
two spools of each module

Detect and interpret the error signaling and system efficiency data

Use the diagnostics maintenance and utility functions offered by the system (system component test, firmware
upgrading, etc.).

How to Use this Manual

The manual is subdivided into 3 sections plus an appendix:
Section 1 – includes the connection diagrams and the electrical interface of the various system components as
well as the instructions for a correct assembly and loading of creels.
Section 2 – lists the possible error messages.
Section 3 – provides the information needed for a correct preventive maintenance of the system.
Appendix A – provides an example of preliminary control procedure (Sign OFF) to be carried out at system reception
time.

Symbols Used

This symbol indicates a safety prescription that must be absolutely adopted to avoid possible risks of
injury.
The background gray color highlights notes, warnings and points which is required more attention

Reference Manuals

For the description and the operating instructions of:
Please refer to the relevant manuals.

MATRIX TOUCH DIAPER terminal

DIAPERFEEDER device

SM-DIN/MULTILOOP Board
MATRIX CUBE (MCC)
