Defining LAG Membership

The LAG Membership Page contains fields for configuring parameters for configured LAGs. The device supports
up to eight ports per LAG, and eight LAGs per system.
To define LAG parameters:
1. Click Advanced Setup > Interface > LAG Membership. The opens.
Figure 34: LAG Membership Page
The LAG Membership Page contains the following fields:
•
LAG No. — Displays the LAG number.
•
Name — Displays the user-defined LAG name on which LACP is enabled.
•
Link State — Displays the link operational status.
•
Members — Displays the ports configured to the LAG.
In addition to the fields appearing on the LAG Membership Page, the LAG Membership Settings Page contains
the following fields:
•
LACP — Indicates if LACP is enabled on LAG. The possible field values are:
–
Checked — Enables LACP on the LAG.
–
Unchecked — Disables LACP on the LAG. This is the default value.
•
Port List — Displays the ports to which timeout and priority values are assigned.
2. Click . The LAG membership settings are saved, and the device is updated.
