Activating Image Files - D-Link Web Smart DES-3252P Install Manual

Activating Image Files

The Active Image Page allows network managers to select and reset the Image files.
To open the Active Image Page :
1. Click System > File Management > Active Image. The Active Image Page opens:
Figure 120:Active Image Page
The Active Image Page contains the following fields:
•
Active Image — The Image file which is currently active on the unit.
•
After Reset — The Image file which is active on the unit after the device is reset. The possible field values
are:
–
Image 1 — Activates Image file 1 after the device is reset.
–
Image 2 — Activates Image file 2 after the device is reset.
2. Define the After Reset field. Click . The select image file is activated after the device is reset.
Page 185
Managing System Files
Activating Image Files
