D-Link Web Smart DES-3252P Install Manual page 184

Configuration Upload
The Configuration Upload section contains the following fields:
•
TFTP Server IP Address — Specifies the TFTP Server IP Address to which the Configuration file is
uploaded.
•
Destination File Name— Specifies the file name to which the Startup Configuration file is uploaded. The sys-
tem can store up-to five configuration files.
•
Transfer file name — Specifies the Configuration file name that is uploaded. In addition to the Startup and
Running Configuration files, the Transfer file name field contains the five defined destination files. The possi-
ble field values are:
–
Running Configuration — Uploads the Running Configuration file.
–
Startup Configuration — Uploads the Startup Configuration file.
To upload files:
1. Open the File Upload Page.
2. Define the file type to upload.
3. Define the fields.
4. Click . The software is uploaded to the device.
Page 184
Managing System Files
Uploading System Files
