Managing RMON Statistics

This section contains the following topics:
•
Viewing RMON Statistics
•
Configuring RMON History
•
Configuring RMON Events
•
Defining RMON Alarms
Viewing RMON Statistics
The Viewing RMON Statistics contains fields for viewing information about device utilization and errors that
occurred on the device. To view RMON statistics:
1. Click Advanced Setup > RMON > Statistics. The RMON Statistics Page opens.
Figure 171:RMON Statistics Page
The RMON Statistics Page RMON Statistics Page contains the following fields:
•
Interface — Indicates the device for which statistics are displayed. The possible field values are:
–
Port — Defines the specific port for which RMON statistics are displayed.
–
LAG — Defines the specific LAG for which RMON statistics are displayed.
•
Refresh Rate — Defines the amount of time that passes before the interface statistics are refreshed. The
possible field values are:
–
15 Sec — Indicates that the RMON statistics are refreshed every 15 seconds.
–
30 Sec — Indicates that the RMON statistics are refreshed every 30 seconds.
Page 247
