D-Link Web Smart DES-3252P Install Manual page 228

•
Filter Name — Indicates if the SNMP filter for which the SNMP Notification filter is defined.
•
Timeout — Indicates the amount of time (in seconds) the device waits before re-sending informs. The default
is 15 seconds.
•
Retries — Indicates the amount of times the device re-sends an inform request. The default is 3 seconds.
•
Remove — Deletes the currently selected recipient. The possible field values are:
–
Checked — Removes the selected recipient from the list of recipients.
–
Unchecked — Maintains the list of recipients.
SNMPv3 Notification Recipient
The SNMPv3 Notification Recipient table contains the following fields:
•
Recipient IP — Displays the IP address to which the traps are sent.
•
Notification Type — Displays the type of notification sent. The possible field values are:
–
Trap — Indicates that traps are sent.
–
Inform — Indicates that informs are sent.
•
User Name — Displays the user to which SNMP notifications are sent.
•
Security Level — Displays the means by which the packet is authenticated. The possible field values are:
–
No Authentication — Indicates that the packet is neither authenticated nor encrypted.
–
Authentication — Indicates that the packet is authenticated.
•
UDP Port — The UDP port used to send notifications. The field range is 1-65535. The default is 162.
•
Filter Name — Includes or excludes SNMP filters.
•
Timeout — The amount of time (seconds) the device waits before resending informs. The field range is 1-
300. The default is 10 seconds.
•
Retries — The amount of times the device resends an inform request. The field range is 1-255. The default is
3.
•
Remove — Deletes the currently selected recipient. The possible field values are:
–
Checked — Removes the selected recipient from the list of recipients.
–
Unchecked — Maintains the list of recipients.
2. Click . The Add SNMP Notification Receiver Page opens:
Page 228
Configuring SNMP
Configuring SNMP Notifications
