4 - Data Types and Shared TLV Data Objects

4.10 EMV Entry Point Configuration File Type

The host uses Command 0xD812 - Start Send File to Device (Unsecured) to load this file type to
control the behavior of the device's EMV kernels.
Table 4.10-1 - EMV Entry Point Configuration File Type Header
Tag Value (hex)
File Type Version
One byte indicating the version of the file type format being used.
•
0xAA
SHA-1 Hash
20 byte hash of all values that follow
One or more instances of the following:
•

Mastercard MCL Entry Point Table

•
Visa payWave Entry Point Table
•
American Express Expresspay Entry Point Table
•
Discover D-PAS Entry Point Table
The host should include an Entry Point Table for each transaction type to be supported by each
contactless payment brand Application Identifier (AID) listed in the loaded EMV Processing
Configuration File Type . For example, if the device should support three transaction types across
each of four payment brands, it would combine 12 total Entry Point Tables into a single file instance
before loading.
4.10.1 Mastercard MCL Entry Point Table
Table 4.10-2 - Mastercard MCL Entry Point Table
Tag Len
AID Delimiter Container
There can be multiple instances of this in sequence. The
FF35 var contents of the first instance are loaded into Entry Point
Table Slot 1, the contents of the second are loaded into
Entry Point Table Slot 2, etc.
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
Page 65 of 301 (D998200597-102)
Description
Typ Req Example
T R
