Property 1.1.1.1.1.3 Emv Batch Data Tag List - Magtek DynaFlex II Go Programmer's Manual

8 - Configuration
Table 8.2-10 - Set Response Example
AA 00 81 04 82 09 D1 11 82 04 00 00 00 00 84 82 00 64 D1 11 81 07 2B 06 01 04 01 F6 09 85 01 01
89 54 E1 52 E1 50 E1 4E E1 4C C2 4A 50 5A 57 82 84 95 9A 9B 9C F4 5F 1A 5F 20 5F 24 5F 2A 5F
30 5F 34 9F 02 9F 03 9F 06 9F 09 9F 10 9F 15 9F 1A 9F 1D 9F 1E 9F 24 9F 26 9F 27 9F 33 9F 34 9F
35 9F 36 9F 37 9F 39 9F 41 9F 45 9F 4C 9F 4E 9F 5D 9F 66 9F 6E 9F 7C

8.2.1.3 Property 1.1.1.1.1.3 EMV Batch Data Tag List

Table 8.2-11 - Property 1.1.1.1.1.3 EMV Batch Data Tag List
Property OID 1.1.1.1.1.3 / 0x010101010103
Name EMV Batch Data Tag List
The device uses this property when it generates an EMV Batch Data Type data object
to contain transaction result data, to determine what tags to include in the data object.
Description
It serves the same purpose that MagTek custom tag DFDF17 serves on some other
MagTek devices.
Securing Key None
Min. Len (b) 0
Max. Len (b) 255
Data Type Binary
Valid Values List of any valid standard EMV message tags and device custom tags
50 57 5A 82 84 8E 95 9A 9C F4 5F 20 5F 24 5F 25 5F 28 5F 2A 5F 2D 5F 34 9F 02 9F
Default 03 9F 07 9F 09 9F 0B 9F 0D 9F 0E 9F 0F 9F 10 9F 11 9F 12 9F 15 9F 16 9F 1A 9F 1C
9F 1E 9F 21 9F 24 9F 26 9F 27 9F 33 9F 34 9F 35 9F 36 9F 37 DF DF 25
Table 8.2-12 - Get Request Example
AA 00 81 04 01 15 D1 01 84 1A D1 01 81 07 2B 06 01 04 01 F6 09 85 01 01 89 0A E1 08 E1 06 E1 04
E1 02 C3 00
Table 8.2-13 - Get Response Example
AA 00 81 04 82 15 D1 01 82 04 00 00 00 00 84 82 00 66 D1 01 81 07 2B 06 01 04 01 F6 09 85 01 01
89 56 E1 54 E1 52 E1 50 E1 4E C3 4C 50 57 5A 82 84 8E 95 9A 9C 5F 20 5F 24 5F 25 5F 28 5F 2A 5F
2D 5F 34 9F 02 9F 03 9F 07 9F 09 9F 0B 9F 0D 9F 0E 9F 0F 9F 10 9F 11 9F 12 9F 15 9F 16 9F 1A 9F
1C 9F 1E 9F 21 9F 24 9F 26 9F 27 9F 33 9F 34 9F 35 9F 36 9F 37 DF DF 25
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Example (Hex)
Property Description
Example (Hex)
Example (Hex)
Page 176 of 301 (D998200597-102)
