8 - Configuration
Table 8.2-14 - Set Request Example
AA 00 81 04 01 0B D1 11 84 66 D1 11 81 07 2B 06 01 04 01 F6 09 85 01 01 89 56 E1 54 E1 52 E1 50
E1 4E C3 4C 50 57 5A 82 84 8E 95 9A 9C 5F 20 5F 24 5F 25 5F 28 5F 2A 5F 2D 5F 34 9F 02 9F 03
9F 07 9F 09 9F 0B 9F 0D 9F 0E 9F 0F 9F 10 9F 11 9F 12 9F 15 9F 16 9F 1A 9F 1C 9F 1E 9F 21 9F 24
9F 26 9F 27 9F 33 9F 34 9F 35 9F 36 9F 37 DF DF 25
Table 8.2-15 - Set Response Example
AA 00 81 04 82 0B D1 11 82 04 00 00 00 00 84 82 00 66 D1 11 81 07 2B 06 01 04 01 F6 09 85 01 01
89 56 E1 54 E1 52 E1 50 E1 4E C3 4C 50 57 5A 82 84 8E 95 9A 9C 5F 20 5F 24 5F 25 5F 28 5F 2A 5F
2D 5F 34 9F 02 9F 03 9F 07 9F 09 9F 0B 9F 0D 9F 0E 9F 0F 9F 10 9F 11 9F 12 9F 15 9F 16 9F 1A 9F
1C 9F 1E 9F 21 9F 24 9F 26 9F 27 9F 33 9F 34 9F 35 9F 36 9F 37 DF DF 25

8.2.1.4 Property 1.1.1.1.1.4 EMV Reversal Data Tag List (EMV Contact Only)

Table 8.2-16 - Property 1.1.1.1.1.4 EMV Reversal Data Tag List (EMV Contact Only)
Property OID 1.1.1.1.1.4 / 0x010101010104
Name EMV Reversal Data Tag List
The device uses this property when it generates an EMV Batch Data Type data object
to contain reversal data, to determine what tags to include in the data object. It serves
Description
the same purpose that MagTek custom tag DFDF05 serves on some other MagTek
devices.
Securing Key None
Min. Len (b) 0
Max. Len (b) 255
Data Type Binary
Valid Values List of any valid standard EMV message tags and device custom tags
57 5A 82 8A 95 9A 9C 5F 24 5F 2A 5F 34 9F 01 9F 02 9F 10 9F 15 9F 16 9F 1A 9F 1C
Default
9F 21 9F 33 9F 35 9F 36 9F 39 9F 5B DF DF 25
Table 8.2-17 - Get Request Example
AA 00 81 04 01 16 D1 01 84 1A D1 01 81 07 2B 06 01 04 01 F6 09 85 01 01 89 0A E1 08 E1 06 E1 04
E1 02 C4 00
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Example (Hex)
Example (Hex)
Property Description
Example (Hex)
Page 177 of 301 (D998200597-102)
