6 - Commands
Tag Len
•
All other values = Timeout in seconds for the device to
leave the barcode reader enabled without reading a barcode.
Encrypt Barcode Data
•
0x00 = Do Not Encrypt. The device does not encrypt the
barcode data when it sends Notification 0x1805 - User
83 01 Interface Operation Complete.
•
0x01 = Encrypt. The device encrypts the barcode data
when it sends Notification 0x1805 - User Interface
Operation Complete.
End of any wrappers, at minimum including Request Message found on page 32
Table 6.3-6 - Response Data for Command 0x1804 - Read Barcode (BCR Only)
Tag Len
Beginning of any wrappers, at minimum including Response Message found on page 33
1804 = Command 0x1804 - Read Barcode (BCR Only)
No parameters.
End of any wrappers, at minimum including Response Message found on page 33
Table 6.3-7 - Request Example
AA00 810401031804 840B 1804 810101 82010F 830101
Table 6.3-8 - Response Example
AA00 810482031804 820401000000

6.3.3 Command 0x1805 - Buzzer

The host uses this command to start a buzzer for playing a sequence of tones. Each sequence can have a
minimum of 1 to maximum of 10 tones.
The sequence of events is as follows:
1) The host ensures the device is not currently running another command, for example, that it is not
running a transaction using Command 0x1001 - Start Transaction.
2) The host composes a command request in the format below and sends it to the device.
3) The device plays a specific tone sequence as the command specified. After finish, the device sends
Notification 0x1805 - User Interface Operation Complete to report Buzzer/Buzzer Result.
The host should wait for Notification 0x1805 - User Interface Operation Complete before sending
another command.
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
Value / Description
Example (Hex)
Example (Hex)
Page 112 of 301 (D998200597-102)
Typ Req Default
B O 0x00
Typ Req Default
