Magtek DynaFlex II Go Programmer's Manual page 120

6 - Commands
Tag Len
This can also be populated with fewer numbers from the OID,
in which case the remaining numbers of the OID of the
Property or set of Properties you wish to retrieve must be
included in the Property OID Remainder.
For simplicity, populate this with the 2
last number in the property's OID.
Property OID Remainder
This contains the remaining numbers of the Property's OID,
BER TLV encoded per X.660 section 8 Basic encoding rules.
For details about TLV encoding an OID. To request a set of
properties in a branch of the Property OID structure, the host
should pass a partial Property OID, and the device returns the
89 var value of all properties from the specified tree level downward.
For simplicity, include all numbers except the final number of
the property's OID in Property Type and Property OID Tree
Prefix, and include the final number of the OID OR 0xC0 here,
then append constant byte 0x00. These two bytes represent a
single empty BER TLV primitive data object.
End of any wrappers, at minimum including Request Message found on page 32
Table 6.5-2 - Response Data for Command 0xD101 - Get Property
Tag Len
Beginning of any wrappers, at minimum including Response Message found on page 33
D101 = Command 0xD101 - Get Property
Company ID
This contains the Company ID the host included in the request
81 var
message. If this parameter is not included in the request, the
response does not include it.
Device Family ID
This contains the Device Family ID the host included in the
82 03
request message. If this parameter is not included in the
request, the response does not include it.
Property Type
85 01 This contains the Property Type the host included in the request
message.
Property OID Tree Prefix
This contains the Property OID Tree Prefix the host included in
87 var
the request message. If this parameter is not included in the
request, the response does not include it.
89 var Property OID Remainder
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
nd
through the second-to-
Value / Description
Page 120 of 301 (D998200597-102)
Typ Req Default
B R
Typ Req Default
B O N/A
B O N/A
B R N/A
B O N/A
B R N/A
