Magtek DynaFlex II Go Programmer's Manual page 129

6 - Commands
If the request started successfully, the Request Status in the message wrapper is OK, Started / Running,
All good / requested operation was successful.
Table 6.6-4 - Request Example
AA 00 81 04 01 01 D8 01 84 83 0C 76 58 D8 01 81 01 03 85 02 00 01 86 20 DF C7 1E 09 A3 CE 8E 86
B0 F5 B6 75 BE B7 7A 0E 82 33 BF F1 8A CD 8F 38 34 B0 DB 20 D9 40 4B 28 87 83 0C 76 28
Plus 0C7628 bytes of firmware Payload, excluded here for brevity.
Table 6.6-5 - Response Example
AA 00 81 04 82 01 D8 01 82 04 00 00 00 00
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Example (Hex)
Example (Hex)
Page 129 of 301 (D998200597-102)
