Magtek DynaFlex II Go Programmer's Manual page 50

4 - Data Types and Shared TLV Data Objects
Tag Len
Byte 6 – Alternate Interface Preference
0x10 = Contact
0x20 = MSR
0xF0 = N/A
Byte 7 – Field Off Request
FF = N/A
Byte 8 – Removal Timeout
/F4 var Container for encrypted MSR data (MSR Only)
Encrypted Track 1 Status (MSR Only)
•
•
//DFDF36 01
•
•
//DFDF37 var Encrypted Track 1 Data (MSR Only)
Encrypted Track 2 Status (MSR Only)
•
•
//DFDF38 01
•
•
//DFDF39 var Encrypted Track 2 Data (MSR Only)
Encrypted Track 3 Status (MSR Only)
•
•
//DFDF3A 01
•
•
//DFDF3B var Encrypted Track 3 Data (MSR Only)
Encrypted MagnePrint Data (MSR Only)
//DFDF3C var Only included for MSR swipe transactions and when Track
Data and Magneprint are using the same KSN.
MagnePrint Status Data (MSR Only)
Only included for MSR swipe transactions and when Track
Data and Magneprint are using the same KSN.
•
//DFDF43 04
•
•
•
•
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
0x00 = OK
0x01 = Empty
0x02 = Error
0x03 = Disabled
0x00 = OK
0x01 = Empty
0x02 = Error
0x03 = Disabled
0x00 = OK
0x01 = Empty
0x02 = Error
0x03 = Disabled
Bit 0 = MagnePrint Capable Flag
o 0 = Device is not MagnePrint capable
o 1 = Device is MagnePrint capable
Bits 1 through 3 = Mode
o 0 = Standard MagnePrint
o 1 = Extended MagnePrint
Bits 4 through 15 = ASIC Revision
Bit 16 = Reserved
Bit 17 = Reserved
Page 50 of 301 (D998200597-102)
Typ Req Default
T O
B O
B O
B O
B O
B O
B O
B O
B O
