8 - Configuration
Table 8.3-9 - Set Request Example
AA00 81040155D111 8410 D111 850101 870402010101 8903 C20103
Table 8.3-10 - Set Response Example
AA 00 81 04 82 55 D1 11 82 04 00 00 00 00 84 82 00 10 D1 11 85 01 01 87 04 02 01 01 01 89 03 C2
01 03

8.3.1.3 Property 1.2.1.1.2.1 Signature Capture Control

Table 8.3-11 - Property 1.2.1.1.2.1 Signature Capture Control
Property OID 1.2.1.1.2.1 / 0x010201010201
Name Signature Capture Control
The host can use this property to change whether the device automatically prompts the
Description cardholder for a signature when running Command 0x1001 - Start Transaction, or
leaves the triggering of signature capture prompts to the host.
Securing Key None
Min. Len (b) 1
Max. Len (b) 1
Data Type Binary
0x00 = Device-driven Signature Capture
Valid Values
0x01 = Host-driven Signature Capture
Default 0x00
Table 8.3-12 - Get Request Example
AA 00 81 04 01 04 D1 01 84 1A D1 01 81 07 2B 06 01 04 01 F6 09 85 01 01 89 0A E2 08 E1 06 E1 04
E2 02 C1 00
Table 8.3-13 - Get Response Example
AA 00 81 04 82 04 D1 01 82 04 00 00 00 00 84 82 00 1B D1 01 81 07 2B 06 01 04 01 F6 09 85 01 01
89 0B E2 09 E1 07 E1 05 E2 03 C1 01 01
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Example (Hex)
Example (Hex)
Property Description
Example (Hex)
Example (Hex)
Page 211 of 301 (D998200597-102)
