6.4.2 Command 0x1F02 - Set Notification Subscriptions

The host uses this command to specify which notifications the device should send on each of its available
interfaces. By default, the device sends notifications to the host on all interfaces.
The sequence of events is as follows:
1) The host constructs the command request in the format below.
2) The host sends the command request to the device.
3) The device sends a response in the format below to the host.
4) The device immediately begins routing notifications per the request.
5) If the device restarts or loses power, the device resets its notification subscriptions to defaults, and the
host must call this command again to change them.
Table 6.4-5 - Request Data for Command 0x1F02 - Set Notification Subscriptions
Tag Len
Beginning of any wrappers, at minimum including Request Message found on page 32
1F02 = Command 0x1F02 - Set Notification Subscriptions
Subscribe
•
81 01 0x00 = Unsubscribe
•
0x01 = Subscribe
Notifications Affected
•
0x00 = Only subscribe or unsubscribe to notification
82 01
messages in the Notification Message ID List parameter
•
0x01 = Subscribe or unsubscribe to all notifications
Notification Message ID List
List of two-byte Notification Message IDs (MSB first) from
section 7 Notifications to be subscribed / unsubscribed by this
command. For example, to subscribe to Notification 0x0105 -
83 var
Transaction Operation Complete on the interface being used
to send this command, the host would include 0x0105 as two
bytes in the list. The device ignores any Notification Message
IDs in the list that do not exist.
Interfaces
List of interfaces this command should change the subscription
A4 var settings for. If the host does not specify any interfaces here, the
command applies only to the interface the host is using to send
the command.
/81 00 Apply changes to the USB interface
/83 00 Apply changes to the Bluetooth LE interface
/84 00 Apply changes to the UART interface
End of any wrappers, at minimum including Request Message found on page 32
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
Page 115 of 301 (D998200597-102)
Typ Req Default
B O 0x01
B O 0x01
B O Null
B O Null
O
O
O
