7 - Notifications
Table 7.4-5 - Notification Payload for Barcode Reader, Read Barcode Result, Success (Encrypted Data
Attached)
Tag Len
Beginning of Notification Message found on page 39
1805 = User Interface Operation Complete
84 var Notification Payload
Encrypted Data Primitive
Decrypt the value of this TLV data object using the
/DFDF59 var algorithm and variant specified in the Encrypted Data KSN
parameter and the Encrypted Data Encryption Type
parameter to read its contents. The format of the decrypted
data is shown in Table 7.4-6.
/DFDF50 var Encrypted Data KSN
Encrypted Data Encryption Type
/DFDF51 01
See section 4.4 Encryption Type for a list of valid values.
End of Notification Message found on page 39
Table 7.4-6 - Notification Payload for Barcode Reader, Read Barcode Result, Success (Unencrypted Data)
Tag Len
FC var Barcode Data Container
/DF74 var Barcode Data
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
Value / Description
Page 172 of 301 (D998200597-102)
Typ Req Default
B R
B R
B R
B R
Typ Req Default
T R
B O
