6 - Commands
If the buzzer is current playing a sequence of tones and any transaction that uses the buzzer to make a
sound is started, the device will stop the buzzer for that transaction to take over.
Table 6.3-9 - Request Data for Command 0x1805 - Buzzer
Tag Len
Beginning of any wrappers, at minimum including Request Message found on page 32
1805 = Command 0x1805 - Buzzer
N = Number of tones
•
•
4 = 4 bytes data parameter for each tone in the sequence
Byte0-Byte1 – Frequency in units of 1 Hz
•
81 N*4
•
•
•
Byte 2-Byte3 – Duration of tone in units of 1 millisecond
•
•
End of any wrappers, at minimum including Request Message found on page 32
Table 6.3-10 - Response Data for Command 0x1805 - Buzzer
Tag Len
Beginning of any wrappers, at minimum including Response Message found on page 33
1805 = Command 0x1805 - Buzzer
No parameters.
End of any wrappers, at minimum including Response Message found on page 33
Table 6.3-11 - Request Example for a sequence of 5 tones
AA00 810401031805 8418 1805 8114 00C8 01F4 0190 01F4 0258 01F4 0190 01F4 00C8 01F4
Table 6.3-12 - Response Example
AA00 810482031805 820401000000
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
0x01 – Min (1 tone)
0x0A – Max (10 tones)
0x0000..0x0031 (< 50 Hz, Silent)
0x0032 - Min (50 Hz)
0x0FA0 - Max (4000 Hz)
0x0FA1..0xFFFF (> 4000 Hz, Error)
0x0001 – Min (1 ms)
0xFFFF – Max (65535 ms)
Value / Description
Example (Hex)
Example (Hex)
Page 113 of 301 (D998200597-102)
Typ Req Default
B R
Typ Req Default
