Appendix A Object IDs (OIDs) and ITU-T X660
A.1

About OIDs

For modular management of device functions, information, and settings, this standard makes extensive
use of Object Identifiers (also known as Object IDs or OIDs) as defined in ITU-T X.660 | ISO/IEC
9834-1, which can be found by searching for X.660 in the publications on www.itu.int.
OIDs are identifiers for any generic data element, and are managed by standards bodies to be globally
unique (much like web domains, IP addresses, and Media Access Control MAC addresses). They are
managed by using a tree structure consisting of nodes, where the tree structure is defined and controlled
by a hierarchy of subordinate Registration Authorities, each with their authority delegated by a
Registration Authority one level higher in the tree, starting with the root nodes managed by ITU-T and
ISO. The X.660 standard for OIDs is harmonized with the data representation standard of ASN.1 via that
standard's OBJECT IDENTIFIER and OID-IRI types. Every node is assigned a primary integer
value (or primary value for short) which serves to uniquely identify the node, and may be assigned
secondary identifiers (such as strings) for human readability.
MagTek is the Registration Authority for the OID tree beginning at {iso(1) identified-organization(3)
dod(6) internet(1) private(4) enterprise(1) MagTek(15113)} (using value notation of the ASN.1
OBJECT IDENTIFIER type). The branch can also be represented in numerical shorthand as
1.3.6.1.4.1.15113, which is the encoding form of the ASN.1 OBJECT IDENTIFIER type.
Per X.660, OIDs can be encoded in constructed form or primitive form. The primitive form is a
sequence of octets (bytes) and is summarized in section A.2 Octet Encoding of OIDs. The constructed
form is a TLV data object and is summarized in section A.3 TLV Encoding of OIDs.
In many cases, the MagTek implementation of OID-based message elements allows the host to specify an
optional Company ID and Tree prefix alongside a Relative OID, where the full OID is a concatenation
of the company ID, followed by the tree prefix, followed by the relative OID. If a message does not
include the optional company ID or tree prefix, company ID is assumed to be the MagTek arc above, and
the tree prefix is assumed to be a reasonable sequence of additional nodes based on the purpose and scope
of the message.
