6 - Commands
Tag Len
Length of File
/81 var
This is the length of the file.
Hash Checksum Type
/82 01
•
0x04 = SHA-256
Hash Checksum
/83 20 Anticipated checksum calculated against the file, according to
the standard specified in Hash Checksum Type.
File Description
A3 var The values the host populated for convenience when it sent the
file to help identify the file. Not all values are required.
File Name
/81 var Maximum length 32 bytes
Reserved for future use.
File Label
/82 var Maximum length 16 bytes
Reserved for future use.
File Version
/83 var Maximum length 7 bytes
Reserved for future use.
File Date
/84 var Maximum length 20 bytes
Reserved for future use.
End of any wrappers, at minimum including Response Message found on page 33
If the request started successfully, the Request Status in the message wrapper is OK, Started / Running,
All good / requested operation was successful.
Table 6.6-20 - Request Example
AA 00 81 04 01 08 D8 21 84 08 D8 25 81 04 00 00 00 01
Table 6.6-21 - Response Example
AA 00 81 04 82 08 D8 25 82 04 00 00 00 00 84 54 D8 25 81 04 00 00 00 01 A2 2B 81 04 00 00 00 40
82 01 04 83 20 FD EA B9 AC F3 71 03 62 BD 26 58 CD C9 A2 9E 8F 9C 75 7F CF 98 11 60 3A 8C 44
7C D1 D9 15 11 08 A3 1D 81 0B 54 45 53 54 5F 31 4B 2E 62 69 6E 82 05 4C 61 62 65 6C 83 07 31 2E
30 2E 30 2E 31
Note: For additional support, please contact MagTek Support.
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Value / Description
Example (Hex)
Example (Hex)
Page 137 of 301 (D998200597-102)
Typ Req Default
B R
B R
B R
T R
B O Null
B O Null
B O Null
B O Null
