6 - Commands
6.6

Command Group 0xD8nn - File Operations

6.6.1 About Files

Large blobs of data uploaded to / downloaded from the device are referred to as "files" and share a
common set of commands documented here, and special message type Data File Message. Some file
types can be sent in the File Payload fields in "raw" form (e.g. certificates and images) with metadata
coming from the command request and response. Other file types require the addition of MagTek
metadata included inside the File Payload blob; these are documented in the "File Type" subsections of
section 4 Data Types and Shared TLV Data Objects.
Files Types that may come from the host include:
•
EMV configuration
•
Firmware updates
•
Public Key Infrastructure (PKI) Certificates
•
User interface images and prompts
•
EMV kernels
•
SRED BIN tables
File Types that may come from the device include:
•
Read back of the above file types
•
Signature Capture
•
Logs
•
Certificate Requests
The commands in this section share a common list of 4-byte file types, listed in Table 6.6-1. File types
marked as Secured = Yes must be loaded using Command 0xD811 - Start Send File to Device
(Secured); file types that are marked as Secured = No can be loaded using Command 0xD812 - Start
Send File to Device (Unsecured).
Table 6.6-1 - File Types
Description
EMV configuration, terminal file. See file
definition in section 4.8 on page 61.
EMV configuration, processing file. See
file definition in section 4.9 on page 62.
EMV configuration, entry point file. See
file definition in section 4.10 on page 65.
EMV configuration, CA keys file. See
file definition in section 4.11 EMV
Configuration CA Public Keys File Type
on page 75.
EMV configuration, Visa DRL set.
Reserved for future use.
DynaFlex II Go| Secure Card Reader | Programmer's Manual (COMMANDS)
Secured
Get: No
0x00
Set: No
Get: No
0x00
Set: No
Get: No
0x00
Set: No
Get: No
0x00
Set: No
Get: No
0x00
Set: No
Page 126 of 301 (D998200597-102)
File File Type File
Type Version Subtype
0x00 0x00
0x00 0x01
0x00 0x02
0x00 0x03
0x00 0x04
File
Instance
0x00
0x00
0x00
0x00
0x00
