3.2 Programming

The keyboard
allows to program the following variables appearing on the display:
VARIABLE
PROBE
M.UNIT
M.RANGE
SET N.VA
M.RESOL
UpperTOL
LowerTOL
MASTER
M. TYPE
SCALE
PreTRAV1
PreTRAV2
K1
K2
BARGRAPH
DIGITSET
DIGITDIR
SYST. ID
COM. MODE
QRbin / ASCII
I/O
BAUD
PARITY
STR. END
Press PROG for two seconds to enter the programming mode from measuring mode.
NOTE 1:
The message "ALARM 80" is displayed by pressing PROG if Quick Read is in "SET-UP" mode
instead of measuring mode.
Press SETUP to return to measuring mode.
ESC PROG SETUP ZERO
DYN ENTER
Number of sensors to be connected
Measuring unit
Measuring range (this variable can be programmed only in the
Microcolumn model)
Nominal value of the measure
Digital display resolution.
This variable appears only if M.RANGE = ± 0,250 / ± 0,500 / ± 1,000
mm (± .010" / ± .020" / ± .040") and SET N.VA = 0.
Upper tolerance limit
Lower tolerance limit
Master deviation
Measurement type
Analog display scale range (full scale)
Pretravel check on sensor 1
Pretravel check on sensor 2 (this variable is displayed only if the
connection of two sensors has been programmed)
Multiplying coefficient of the transducer signal of the sensor 1
Multiplying coefficient of the transducer signal of the sensor 2 (this
variable is displayed only if the connection of two sensors has been
programmed)
Direction of measurement analog visualization
Digital display on/off
Reading direction of the digital display
Software identification number for serial transmission of the data to PC,
data collectors, BCD interface, PLC.
Type of protocol for serial data transmission
Enable remote zeroing push-button
Baud rate: data transmission speed
Parity bit + data bit + stop bit
String end
_
+
DESCRIPTION
