marposs M1 Star MBG Instruction Manual

Mechanical bore gauge
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instruction Manual
CONGRATULATIONS TO HAVE CHOSEN
Marposs M1 Star MBG (Mechanical Bore Gauge)
Reading this manual will enable you to use the product in the best way,
and to become acquainted with all the system characteristics that mark
it out and make it unique of its kind.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M1 Star MBG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for marposs M1 Star MBG

Summary of Contents for marposs M1 Star MBG

  • Page 1 Instruction Manual CONGRATULATIONS TO HAVE CHOSEN Marposs M1 Star MBG (Mechanical Bore Gauge) Reading this manual will enable you to use the product in the best way, and to become acquainted with all the system characteristics that mark it out and make it unique of its kind.
  • Page 3 This User Manual is supplied only for information purposes. Marposs SpA reserves the right to change the contents of the manual without being obliged to give advance notice of it and/or not to notify any possible modification of the product.

  • Page 4: Table Of Contents

    CHAPTER 1. DESCRIPTION OF MAIN PARTS 6.2 SPECIAL MAINTENANCE CHAPTER 2. ASSEMBLY AND ZERO-SETTING OF INDICATOR CHAPTER 7. LIST OF SPARE PARTS PENCIL PROBE 7.1 STANDARD INDICATOR HOLDER MARPOSS MECHANICAL/ELECTRONIC INDICATORS 7.1.1 COMPONENTS NON-MARPOSS INDICATORS 7.2 MINI INDICATOR HANDLE 7.2.1 COMPONENTS CHAPTER 3.

  • Page 5: Chapter 1. Description Of Main Parts

    DESCRIPTION OF MAIN PARTS Chapter 1 - DESCRIPTION OF MAIN PARTS Thanks to the extreme flexibility of the MBG bore gauge, it is possible to achieve the configuration that is most suitable to any individual requirement. The graphic representation below identifies the main parts of the bore gauge, which will be analyzed in detail further on.

  • Page 6: Chapter 2. Assembly And Zero-Setting Of Indicator

    PENCIL PROBE The operations sequence varies according to the model purchased: a) Bore gauge WITH Marposs pencil probe (or compatible) mechanically installed and zero set (follow SET-UP A procedure) b) Bore gauge WITHOUT pencil probe installed (follow SET-UP B procedure) SET-UP A 1.

  • Page 7: Components 5,5 - Ø

    ASSEMBLY AND ZERO SETTING OF INDICATOR 9. Manually screw the ring nut “C” until its stopped, trying to maintain the zero-setting. Firmly apply the 13mm A/F wrench to threaded connection “E”, and then lock the ring nut “C” by means of the 16mm A/F wrench (see fig. 7). 10.

  • Page 8: Marposs Mechanical/Electronic Indicators

    ZERO SETTING OF INDICATOR MARPOSS MECHANICAL/ELECTRONIC INDICATORS In order to complete the bore gauge, it is necessary to assemble the display dial and to follow the quick set-up procedure described below, which is suitable only for indicators with Marposs characteristics.

  • Page 9: Non-Marposs Indicators

    QUICK DIGIT: Push the RESET button to zero the indicator. NON-MARPOSS INDICATORS Many indicator models are available on the market, so it is difficult to determine a set- up procedure that can meet all needs. Table 1 shows the maximum indicator specifications with which the procedure described above can be followed.

  • Page 10: Chapter 3. Replacement Of Parts And Components

    The plug gauge is the basic element of the bore gauge, because it contains all the movement-transduction technology. It is supplied completely assembled (see Fig. 1), calibrated and tested at the Marposs center. Figure 2 shows all the components that form the plug gauge and that can be replaced in case of wear.

  • Page 11: Replacement Of Plug Gauge

    REPLACEMENT OF PARTS AND COMPONENTS 3.1.1 REPLACEMENT OF PLUG GAUGE RANGE 3-7,5 RANGE 7,5-9,5 RANGE 9,5-300 The plug gauge can be replaced if its components are worn out, or if a retooling is required in order to measure a different diameter. For retooling procedures it is important to consider that the size of thread “M”...
  • Page 12 REPLACEMENT OF PARTS AND COMPONENTS ASSEMBLY OF PLUG GAUGE “1” ATTENTION In case of substitution of the plug gauge with one of bigger diameter, make sure that the stem does not compress the sensor so as to reach the limit stop. This circumstance may demage both the sensor and the plug gauge.

  • Page 13: Cap Removal

    REPLACEMENT OF PARTS AND COMPONENTS 3.1.2 CAP REMOVAL “A” The cap is a component always supplied with the plug gauge and/or complete application. Its function is to preserve the mechanical elements inside the plug gauge from the penetration of coarse solid matter such as chips. The cap can be removed in order to clean the mechanical transduction assembly and/ or to replace some components within the plug gauge.
  • Page 14 REPLACEMENT OF PARTS AND COMPONENTS DISASSEMBLY OF CAP IN PLUG GAUGES FOR 120 - < 300 Ø 1. As shown in Fig. 4, apply the 2 mm hexagonal-end wrench and unscrew the 4 screws. 2. Extract the 2 half clamps from the plug gauge. 3.

  • Page 15: Contacts Replacement

    MARPOSS office, in order to get detailed gauge. The table below indicates and represents the specifications of the contacts and information on the application.
  • Page 16 REPLACEMENT OF PARTS AND COMPONENTS TECHNICAL T TECHNICAL T TECHNICAL TABLE TECHNICAL T TECHNICAL T ABLE ABLE ABLE ABLE CONTACT WRENCH TABLE D D D D D R R R R R IAMETRICAL IAMETRICAL IAMETRICAL IAMETRICAL IAMETRICAL ANGE ANGE ANGE ANGE ANGE ANGE...
  • Page 17 REPLACEMENT OF PARTS AND COMPONENTS DISASSEMBLY OF CONTACTS 1. Unscrew the contact and disassemble it, using the appropriate wrench (see Table of Contacts). ASSEMBLY AND POSITIONING OF CONTACTS The positioning of the contact depends on the type of measuring armset that is being used (see Table of contacts).
  • Page 18 REPLACEMENT OF PARTS AND COMPONENTS DIAMETER ADJUSTMENT OF TD1P INDICATOR 1. Insert and lock the indicator in the indicator holder by means of the 2 mm hexagonal- end wrench (see Fig. 4) at a 7 mm “A” dimension. 2. Loosen the ring nut “1” by means of a 16mm A/F or with a 2mm hexagonal wrench (see Fig.

  • Page 19: Disassembly Of Nosepiece/Armset

    REPLACEMENT OF PARTS AND COMPONENTS PARALLELO- 3.1.4 DISASSEMBLY OF NOSEPIECE/ARMSET ARMSETS GRAM 3-Ø<5,5 5,5-Ø<7,5 7,5-Ø<9,5 9,5-Ø<26 26-Ø<300 NOSEPIECE: NOSEPIECE: NOSEPIECE: NOSEPIECE: NOSEPIECE: The nosepiece (see Fig. 1) is the guiding element that makes the measurement independent from the operator’s manual skill. Despite its considerable hardness, it is subject to wear, therefore it can be removed and replaced with a new or reconditioned one.
  • Page 20 DISASSEMBLY/ASSEMBLY OF NOSEPIECE/MEASURING ARMSET FOR RANGE 5,5 - 26 mm Special tools are required to disassemble and assemble these components, in order to ensure the proper nosepiece/measuring armset coupling. Due to this reason it is strongly recommended to contact the nearest MARPOSS office.
  • Page 21 REPLACEMENT OF PARTS AND COMPONENTS DISASSEMBLY OF NOSEPIECE/MEASURING ARMSET FOR RANGE 26 - 300 mm 26-300 ATTENTION In order to remove the NOSEPIECE and the MEASURING ARMSET, it is advisable to be 23 A/F equipped with the required wrenches. Fig. 1 represents the seats to apply the wrenches 16 A/F specified in the relevant table.
  • Page 22 REPLACEMENT OF PARTS AND COMPONENTS ASSEMBLY OF NOSEPIECE/MEASURING ARMSET FOR RANGE 26 - 300 mm ATTENTION in order to ensure the correct mutual position of the measuring armset and the nosepiece, both components are equipped with a centering and mating reference. 1.

  • Page 23: Disassembly Of Bushing, Rod And Spring

    REPLACEMENT OF PARTS AND COMPONENTS 3.1.5 DISASSEMBLY OF BUSHING, ROD AND SPRING 3≤ø<5,5 5,5≤ø<7,5 7,5≤ø<9,5 9,5≤ø26 26≤ø Together with the indicator, the spring supplies the measuring force of the contacts on 2,5 A/F 2,5 A/F the part to be measured. It can be removed in order to decrease the measuring force of the contacts.
  • Page 24 REPLACEMENT OF PARTS AND COMPONENTS DISASSEMBLY OF BUSHING FOR RANGE 7.5 - 300 mm 1. Disassemble the plug gauge from the handle (see page 11). 2. Unscrew bushing “2” by means of wrench “B” (see Fig. 1). 3. Extract bushing “a”, spring “b”and rod “c” from the measuring armset (see Fig. 2). ASSEMBLY OF BUSHING FOR RANGE 7,5 - 300 mm 1.

  • Page 25: Handle

    REPLACEMENT OF PARTS AND COMPONENTS 3.2 HANDLE PENCIL PROBE INDICATOR HOLDER HOLDER The handle, besides ensuring the handiness of the plug gauge by conforming to the anatomy of the hand, is also the element that connects the indicator to the plug gauge.

  • Page 26: Pencil Probe Holder

    REPLACEMENT OF PARTS AND COMPONENTS 3.2.1 PENCIL PROBE HOLDER Its ergonomic shape and easy, safe operation ensure functionality. A cable guide and cable clamp protect the pencil probe cable. (See Fig. 2): COMPONENTS CABLE GUIDE THREADED BUSHING HANDLE REMOVABLE NUMBER PLATE COLLET CABLE CLAMP TAPERED NUT...
  • Page 27 REPLACEMENT OF PARTS AND COMPONENTS DISASSEMBLY OF COMPONENTS 1. Applying the 13mm A/F wrench to the threaded connection seat “L ” (see Fig. 3), unscrew and extract the unit formed by “L ” + “I” + “H” + “G” + “F” (see Fig. 4). 2.

  • Page 28: Indicator Holder Handles

    REPLACEMENT OF PARTS AND COMPONENTS 3.2.2 INDICATOR HOLDER HANDLES Two models of indicator holder handles are available: 1. STANDARD INDICATOR HOLDER HANDLE (see Fig. 1); 2. MINI INDICATOR HOLDER HANDLE (see Fig. 2), for small diameters plug gauges. 3.2.2.1 STANDARD INDICATOR HOLDER HANDLE COMPONENTS STANDARD MINI INDICATOR HOLDER...

  • Page 29: Chapter 4. Optional Accessories

    OPTIONAL ACCESSORIES Chapter 4. - OPTIONAL ACCESSORIES In order to ensure the utmost modularity of the system, a set of optional accessories “A” that can meet all sorts of application needs has been developed. M3,5 x 0,35 M6 x 0,75 M3,5 x 0,35 “B”...

  • Page 30: Angle

    OPTIONAL ACCESSORIES 4.2 ANGLE ADAPTOR The angle accessory (see Fig. 1) is used in those measurements where limited space is available, such as those in a machine, and where the bore is in a position that requires a 90° tilting of the measuring axis. ASSEMBLY 1.

  • Page 31: Depth Stops

    OPTIONAL ACCESSORIES 4.3 DEPTH STOPS The depth stops are mechanical stops that are used to fix the measuring section at a predetermined depth. They are divided into two categories: 1. depth stops that can be fastened to the depth extension (see Fig. 1); 2.
  • Page 32 OPTIONAL ACCESSORIES FOR DEPTH EXTENSION, DIAMETER 15 mm 1. Disassemble the depth extension from the handle (or the plug gauge from the depth extension) (see fig. 1). 2. Insert the depth stop in the depth extension and lock it at the desired height A (*), by screwing the M5 dowel by means of the 2.5 mm hexagonal-end wrench (see Fig.

  • Page 33: Assembly Of Nosepieces Depth Stops

    OPTIONAL ACCESSORIES 4.3.2 ASSEMBLY OF NOSEPIECES DEPTH STOPS This model is directly fitted on the outside diameter of the nosepiece and attached to it (see Fig. 1). It is adjusted to the diameter of the nosepiece. 1. Insert the depth stop in the nosepiece and set it at the required height A; this value varies according to the depth in which the measurement needs to be detected (see Fig.

  • Page 34: Hooks

    OPTIONAL ACCESSORIES 4.4 HOOKS In bore gauges with pencil probe holder it is possible to fit an eye (see Fig. 1), in order to make it possible to hang the appliance to a hook, avoiding the presence of the cable on the worktable. ASSEMBLY 1.

  • Page 35: Depth Extensions

    OPTIONAL ACCESSORIES 4.5 DEPTH EXTENSIONS M10 X 0,75 The depth extensions (see Fig. 1) make it possible to reach measuring depths up to 13 A/F 500 mm and even more, if they are connected in cascade. Fig. 1 shows the three manufactured models, in order to comply with the most operating M6X 0,75 needs.

  • Page 36: Rotary Spacer

    OPTIONAL ACCESSORIES 4.6 ROTARY SPACER The rotary spacer (see Fig. 1) allows to perform dynamic measurements while keeping the indicator constantly facing the operator. M6 x 0,75 M10 x 1 NOTE M10 x 1 the table in Fig. 1 will help you in the assembly, indicating the size of the wrenches to be used and the connection threads.

  • Page 37: Chapter 5. Troubleshooting

    TROUBLESHOOTING Chapter 5. - TROUBLESHOOTING MALFUNCTION CORRECTIVE ACTION The malfunction is generally caused by the following reasons: Wearing of one of these elements: • Contacts • Mechanical transducer unit and/or transmission unit Loosening of one of these components: • Contacts and/or contact extension from the measuring MALFUNCTION CORRECTIVE ACTION armset...

  • Page 38: Repeatability Test

    TROUBLESHOOTING 5.1 REPEATABILITY TEST 1. Lean on a horizontal surface the measuring master (minimum diameter) 2. Insert the bore gauge in the master and set to zero the indicator (see Fig. 1); leave the bore gauge in this position for 5 minutes, in order to be properly settled. 3.

  • Page 39: Chapter 6. Maintenance

    M A I N T E N A N C E Chapter 6. - MAINTENANCE Two are the types of maintenance operation planned: • ORDINARY MAINTENANCE (on regular basis, in order to ensure the metrological features of the bore gauge) •...

  • Page 40: Special Maintenance

    NOTE The Special Maintenance operation for range between 3÷26 mm must be carried out by a MARPOSS centre. Whereas, for range between 26÷300 mm, plase follow the instuctions here reported. Remove the plug gauge from the handle (see page 12).

  • Page 41: Chapter 7. List Of Spare Parts

    LIST OF SPARE PARTS Chapter 7. - 7.1.1 COMPONENTS LIST OF SPARE PARTS This chapter indicates all the spare assemblies and/or components, with the Besides the complete indicator handle, the individual components are supplied as well respective ordering codes. (see the table and the relevant graphic representation). 7.1 STANDARD INDICATOR HOLDER ESCRIPTION The table below indicates all the models of STANDARD indicator handles that are...

  • Page 42: Mini Indicator Handle

    LIST OF SPARE PARTS 7.2 MINI INDICATOR HOLDER 7.2.1 COMPONENTS Besides the complete indicator handle, the individual components are supplied as well The table below indicates all the models of MINI indicator handle that are marketed. (see table and relevant graphic representation). ESCRIPTION 2TCSAS0000 Indicator handle ø...

  • Page 43: Pencil Probe Holder

    LIST OF SPARE PARTS 7.3 PENCIL PROBE HOLDER REF. ESCRIPTION The table below indicates the pencil probe handle model that is marketed. 2T0CCAS000 Cable clamp assembly ø 8 2T0CCAS001 Cable clamp assembly ø 3/8" 2T0PPHS702 Pencil probe holder ø 8 ESCRIPTION 2T0PPHS705 Pencil probe holder ø...

  • Page 44: Plug Gauges

    LIST OF SPARE PARTS 7.4 PLUG GAUGE Radius ø Bore Plug Contact ( Dimension Gauge All the plug gauges are supplied as spare parts. Their coding is based on their technical type inch specifications. Below there is a representation of the pattern of the coding of the plug gauges.

  • Page 45: Nosepieces

    LIST OF SPARE PARTS 7.4.1 NOSEPIECES EASURING RANGE α AUGE TYPE inch In this case, too, the ordering code is a speaking one: see the diagram below. 3-300 0.1181”-11.811” Prefix 3-9,5 0.1181”-0.3740” Minimum diameter of bore to be Marking 3-5,5 0.1181”-0.2165”...

  • Page 46: Measuring Armsets

    LIST OF SPARE PARTS 7.4.2.2 MEASURING ARMSET 5,5 ≤ ≤ ≤ ≤ ≤ < 7,5 Ø 7.4.2 MEASURING ARMSETS On the following pages are listed all the spare part components for the measuring ESCRIPTION armsets. NOT supplied Complete measuring armset 7.4.2.1 MEASURING ARMSET 3 ≤...

  • Page 47: Components 7,5 - Ø

    LIST OF SPARE PARTS 7.4.2.3 MEASURING ARMSET 7,5 ≤ ≤ ≤ ≤ ≤ < 9,5 7.4.2.4 MEASURING ARMSET 9,5 ≤ ≤ ≤ ≤ ≤ < 26 Ø Ø ESCRIPTION ESCRIPTION not supplied not supplied Complete measuring armset for through and blind bores Complete measuring armset for through and blind bores not supplied not supplied...

  • Page 48: Components 26 - Ø

    LIST OF SPARE PARTS 7.4.2.5 MEASURING ARMSET 26 ≤ ≤ ≤ ≤ ≤ < 300 7.4.3 CONTACTS Ø All the contacts are supplied as spare parts. Their coding is based on their technical specifications. Below there is a representation of the coding pattern of the contact. ESCRIPTION Complete measuring armset for Blind and Through bores 2TEM9PE000...
  • Page 49 LIST OF SPARE PARTS Length: of contact expressed in mm with a hundredth of a mm IAMETER LUG GAUGE TYPE LUG GAUGE TYPE resolution LASS THROUGH BORES SUPER BLIND BORES UNGSTEN CARBIDE OR IAMOND IDIA OE Sundry: these data depend by the diameter class of the plug gauge, (inch) R1 (mm) R2 (mm)

  • Page 50: Accessories

    LIST OF SPARE PARTS 7.5.3 CAPS 7.5 ACCESSORIES The table below shows the caps with their ordering codes, on the basis of the diameter 7.5.1 THREAD ADAPTORS class and/or type of plug gauge (for through/blind bores, or for super blind bores). In order to ensure the mating between the handles and all the plug gauges in the program, 3 different thread adaptors are DIAMETER CLASS...

  • Page 51: Depth Stops

    LIST OF SPARE PARTS 7.5.4 DEPTH STOPS 1TC0000769 120 ≤ ø < 130 Two different models of depth stops are marketed. 1TC0000770 130 ≤ ø < 140 1TC0000771 140 ≤ ø < 150 7.5.4.1 DEPTH STOPS FOR EXTENSIONS 1TC0000772 150 ≤ ø < 160 Two types of this model are marketed: one is 1TC0000773 160 ≤...

  • Page 52: Depth Stops For Nosepiece

    LIST OF SPARE PARTS 7.5.5 HOOKS 7.5.4.2 DEPTH STOPS FOR NOSEPIECES ESCRIPTION This model is applied directly to the nosepiece, so the inside 1T0JHS0810 diameter of the depth stop depends on the outside diameter T-HOOK 1T0JHS0811 of the nosepiece. 7.5.6 EXTENSIONS The pattern of the speaking code for depth stops for nosepieces is shown below.

  • Page 53: Rotary Spacer

    Pencil probe H10 (HBT) – without connector (L=3,5 m) 3441559045 F10 (LVDT) cable length L=2 m and Lumberg connector S3 3441559046 F10 (LVDT) cable length L=5 m and Lumberg connector S3 ø 8 ø 4,7 For compatible models with NON-MARPOSS electronics, please contact the nearest MARPOSS office.

  • Page 54: Mechanical Indicator

    7.6.2 MECHANICAL INDICATORS 7.6.3 ELECTRONIC INDICATOR Three different models of mechanical indicators are marketed. Their technical The table below indicates the models of QUICK DIGIT Marposs electronic indicators specifications are indicated in the table below. that are marketed, with their technical specifications.

  • Page 55: Wrenches For Retooling/Reconfiguration/Maintenance

    LIST OF SPARE PARTS 7.7 WRENCHES FOR RETOOLING/RECONFIGURATION/MAINTENANCE 7.7.1 WRENCHES FOR CONTACTS See page 16. They are supplied only as an optional accessory, and are used for all the retooling and/ or reconfiguration and/ or maintenance operations indicated in this manual. WRENCHES FOR SPECIAL MAINTENANCE OPERATIONS PECIAL AND OPEN PECIFICATIONS...
  • Page 56 LIST OF SPARE PARTS NOTES: NOTES:...
  • Page 57 LIST OF SPARE PARTS NOTES: NOTES:...
  • Page 58 MARPOSS, logo and other names/signs, related to Marposs products, cited or showed in this document are registered marks or MARPOSS marks in the United Sta- tes or in other countries. Rights of third parties on marks or registered marks, cited in the present document, are acknowledged to the relevant owners.
