TS30 90° - TOUCH PROBE for TOOL PRESETTING...
Overall dimensions ....................13 Technical specifications ..................14 4. INSTALLATION ........................15 Mounting the TS30 90° on the machine table ............. 15 Mounting the stylus and crash protection pin ............16 Mounting the air blower (if present) ..............17 Aligning the TS30 90° system ................18 4.4.1...
Page 6
TS30 90° - TOUCH PROBE for TOOL PRESETTING...
Original version This document was originally issued in Italian language. Should there be any disputes due to the translations, even if made by MARPOSS the reference text will be the Italian version only. Final test and warranty The company's warranty covers the faults in materials and execution: •...
Page 8
The correct reference ensures quick and accurate answers. In the event of a fault condition that requires the assistance of Marposs personnel, contact the nearest service centre (visit the website www.marposs.com for a list of distributors).
Therefore, repositioning and/or modifications or maintenance operations not covered by the technical documentation shall be considered arbitrary. Marposs S.p.A. declines all responsibility for the consequences of the failure to observe these safety instructions. 2.1.1 Selecting the operator The Operator is defined as the person or persons assigned to install, operate, regulate, clean, repair and move a machine, or carry out repair work on it.
In order to guarantee the complete safety of the operator, this list is not comprehensive. The operator shall be responsible for ensuring that the personal protection systems that are obligatory in the production environment (factory) and prescribed by the employer are complete. TS30 90° - TOUCH PROBE for TOOL PRESETTING...
3. GENERAL DESCRIPTION OF THE SYSTEM TS30 90°Tool setter is a Hard wired compact application with integrated interface for tool setting on machining centres table. The system consists of a Mida TT30 probe and may be used for the following checks: •...
Page 12
To prevent this, an air blower may be fitted on the rear of the probe body (upon request). Air blower The air blower is available in two versions that used the same adjustable support: Standard air blower Optimized air blower Figure 33. Air blowers. TS30 90° - TOUCH PROBE for TOOL PRESETTING...
AMBIENT OPERATING CONDITIONS Relative humidity working conditions 50 - 95% Working temperature Between 10° and 40° C (50° - 104° F) Storage temperature Between -20° and 70° C (-4° - 158° F) TS30 90° - TOUCH PROBE for TOOL PRESETTING...
4. INSTALLATION Mounting the TS30 90° on the machine table 1. Position the base (A) on the machine table and secure it by tightening the central screw (B). During this phase, the base is broadly aligned (100-200 μm) with one of the machine axes, by means of a gauge/set square on the straight part of the base.
Secure the contact support (C) to the protection device (A) using the screw (D). • Insert the contact (E) in the support (C) and secure it using the screw (F). Figure 43. Mounting the stylus and crash protection pin. TS30 90° - TOUCH PROBE for TOOL PRESETTING...
Mounting the air blower (if present) • Position the air blower (A) on the rear part of the probe body, aligning it with the 2 mounting holes (B). • Adjust the blower so that it is positioned correctly, the secure it using the screws (C). Figure 44.
Aligning the TS30 90° system 4.4.1 Alignment procedure with cylindrical contact 1. Position a comparator gauge on the upper part of the plate and align the upper surface of the contact by adjusting the 2 screws D and D alternately.
4.4.2 Alignment procedure with cubic contact 1. Position a comparator gauge on the upper part of the plate and align the upper surface of the contact by adjusting the 2 screws D and D alternately. 2. Once an acceptable value has been achieved (≤ 5 μm), tighten the 2 screws (D and D applying a torque of 5 Nm.
SSR N.O. CONTACT. (Normally Open) 24V GREEN 0 Vcc WHITE (or YELLOW) BLUE SSR RED SSR SSR N.C. CONTACT (Normally Closed) 0V GREEN 24Vcc WHITE (or YELLOW) BLUE SSR RED SSR Figure 45. Electrical connections. TS30 90° - TOUCH PROBE for TOOL PRESETTING...
5. MAINTENANCE WARNING Before carrying out maintenance work, setup the Customer's logic so as to guarantee operator safety. Any machine movement which may injure the operator must be inhibited. Ordinary maintenance 5.1.1 Cleaning and checks To always get the best possible performance from your system, it is good practice to carry out regular cleaning and checks: •...
Page 22
TS30 90° - TOUCH PROBE for TOOL PRESETTING...
