LTOL?

Request from Host
Response from QuickRead
Request of the Lower Tolerance Value.
QuickRead returns the lower tolerance value with string formatted xxxxxxxx as described in
chapter 5 "Formatting of numerical string", page 174.
Example : Request of the Lower Tolerance value on QuickRead with selected metric
system, low resolution and LowerTolerance = -000.150
Request from Host
Response from QuickRead

UTOL?

Request from Host
Response from QuickRead
Request of the Upper Tolerance Value.
QuickRead returns the upper tolerance value with string formatted xxxxxxxx as described in
chapter 5 "Formatting of numerical string", page 174.
Example : Request of the Upper Tolerance value on QuickRead with selected metric
system, low resolution and UpperTolerance = +000.120
Request from Host
Response from QuickRead

MASTER?

Request from Host
Response from QuickRead
Request of the Master Deviation Value.
QuickRead returns the master deviation value with string formatted xxxxxxxx as described
in chapter 5 "Formatting of numerical string", page 174.
Example : Request of the Master Deviation value on QuickRead with selected metric
system, low resolution and MasterDeviation = -000.012
Request from Host
Response from QuickRead

NOMVAL?

Request from Host
Response from QuickRead
Request of the Nominal Value.
QuickRead returns the nominal value with string formatted xxxxxxxx as described in
chapter 5 "Formatting of numerical string", page 174.
ASCII SERIAL TRANSMISSION PROTOCOL
LTOL?
xxxxxxxx
LTOL?
-000.150
UTOL?
xxxxxxxx
UTOL?
+000.120
MASTER?
xxxxxxxx
MASTER?
-000.012
NOMVAL?
xxxxxxxx
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
↵ ↵ ↵ ↵
169
