Disconnect the power cords from the power supplies.
b.
See Disconnect Cables From the
Extend the server to the maintenance position.
c.
See Extend the Server to the Maintenance
Attach an antistatic wrist strap.
d.
See Take Antistatic
Remove the server top cover.
e.
See Remove the Server Top
Locate the PCIe card that you want to remove.
2.
Note:
PCIe slots 1 through 4 are nonfunctional in single-processor systems.
If necessary, record where the PCIe cards are installed.
3.
Unplug all data cables from the PCIe card [1].
4.
Note the cable connections so that it's easier to properly reconnect the cables.
If it is difficult to disconnect the cables from the PCIe card when the card is inserted into
the PCIe slot, consider performing the procedure in Step 5 before completing this step.
Rotate the PCIe card locking mechanism in to an upright position [1], and then lift up on
5.
the PCIe card to disengage it from the motherboard connectors [2].
Server.
Position.
Measures.
Cover.
Chapter 4
Servicing PCIe Cards (CRU)
4-19
