Server Node Back Panel Status Indicators
See a listing of the various back panel status indicators for the Oracle Database Appliance
X10-HA server node.
The following figure shows the Oracle Database Appliance X10-HA server node back panel
and includes indicators for the system, power supplies and network ports.
Oracle Database Appliance X10-HA Status Indicators
Indicator/LED: Color
Top fan: amber
Rear PS: amber
Over temperature warning:
amber
Service processor (SP): green
DO NOT SERVICE: white
State Meaning
Indicates that one (or more) of
the internal fan modules has
failed.
•
Off - Indicates steady
state; no service is
required.
•
On - Indicates service
required; service the
failed fan module.
Indicates that one (or more) of
the power supplies has failed.
•
Off - Indicates steady
state; no service is
required.
•
On - Indicates service
required; service the
failed power supply.
•
Off - Normal operation; no
service is required.
•
On - The system is
experiencing an over
temperature warning
condition.
This is a warning indication,
not a fatal over temperature.
Failure to correct this condition
might result in the system
overheating and shutting down
unexpectedly.
•
Off - The service
processor (SP) is not
running.
•
On - The SP is fully
operational.
•
Slow blink - SP is booting.
Indicates that the system is
not ready to service.
•
Off - Normal operation.
•
On - The system is not
ready for service.
The DO NOT SERVICE
indicator is application
specific. This indicator is only
illuminated on demand by the
Host application.
Chapter 1
1-9
