Caution:
These procedures require that you handle components that are sensitive to
electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in
Discharge
Caution:
Ensure that all power is removed from the server before removing or installing
DIMMs, or damage to the DIMMs might occur. You must disconnect all power
cables from the system before performing these procedures.
The topics and procedures in this section provide information to assist you when replacing a
DIMM or upgrading DIMMs.
•
DIMM and Processor Physical Layout
•
DIMM Population Scenarios
•
DIMM Population Rules
•
Populating DIMMs for Optimal System Performance
•
Using the Server Fault Remind Button
•
Identify and Remove a DIMM
•
Install a DIMM
DIMM and Processor Physical Layout
The physical layout of the DIMMs and processor(s) is shown in the following figure. When
viewing the server from the front, processor 0 (P0) is on the left.
