Returning Oracle Database Appliance to
Operation
Perform tasks to return the Oracle Database Appliance to operation after service.
•

Install the Air Baffle

• Install the Server Top Cover
• Remove Antistatic Measures
• Reinstall the Server Into the Rack
• Return the Server to the Normal Rack Position
• Install the Cable Management Arm (Optional)
• Powering On Oracle Database Appliance
Install the Air Baffle
Install the air baffle by placing it into the server and lowering it to its inserted position.
1.
To install the air baffle, the baffle must fit around the processor heatsinks, then lifted up
about 50 degrees. Locate the tabs on the air baffle so that one tab on each side is under
the lip of the fan tray, and the others are on top of the fan tray.
Consider your next step:
2.
• If you removed the air baffle as part of another procedure, return to that procedure.
