See
From the front of the server on both sides, pull the gray slide-rail release tabs
4.
toward the front of the server, and pull the server out of the rack until it is free of
the rack rails [1 and 2].
Use a mechanical lift or two people to remove the chassis from the rack and
transport it.
A slide-rail release tab is located on each slide-rail.
Set the server on a sturdy, ESD safe work surface.
5.
Take Antistatic Measures
Prepare an antistatic surface on which to set parts during removal and installation.
1.
Place electrostatic discharge ESD-sensitive components such as the printed
circuit boards on an antistatic mat. You can use the following items as an antistatic
mat:
•
•
•
Attach an antistatic wrist strap.
2.
When servicing or removing server components, attach an antistatic strap to your
wrist and then to a metal area on the chassis. Then perform procedures for
servicing the server.
Extend the Server to the Maintenance
Note:
To pull the gray slide-rail release tab, place your finger in the center of
the tab, not on the end, and apply pressure as you pull the tab toward
the front of the server.
Antistatic bag used to wrap a replacement part
Oracle ESD mat (orderable item)
Disposable ESD mat (shipped with some replacement parts or optional system
components)
Preparing the Server for Component Replacement
Position.
Chapter 2
2-18
