Oracle Database Appliance X10-HA Storage Shelf Hot Pluggable Components
Callout
1
2
3
4
5
6
7
If any of the indicators are amber, or if the power supply status indicator does not light,
replace the power supply.
Description
AC power fail indicator
Fan fail indicator
Power supply status indicator
DC power fail indicator
Release lever
AC connector
This switch is non-functional in this product.
The AC power cord is used to apply or
disconnect power to the power supply.
Chapter 3
3-18
