Remove the Motherboard Assembly

• Install the Motherboard Assembly
Remove the Motherboard Assembly
• Use ESD gloves (not latex or vinyl), if possible, when handling components.
• Obtain a Torx T20 screwdriver for processor socket external cap removal.
• Obtain a Torx T25 screwdriver for motherboard removal.
• Obtain a small flat blade screwdriver for light pipe removal from the old
motherboard.
Caution:
Use the Oracle ILOM backup utility prior to removing the motherboard. This
utility backs up the Oracle ILOM configuration of the service processor. Refer
to
Prepare the server for service.
1.
a.
b.
c.
d.
e.
f.
Remove the air baffle.
2.
See
Remove the fan modules.
3.
See
Remove the fan tray.
4.
See
Remove all PCIe cards.
5.
See
Remove the power supplies.
6.
See
Oracle ILOM Documentation.
Power off the server.
See Powering Down the Server.
Disconnect the power cords from the power supplies.
See Disconnect Cables From the
Remove rear panel cables.
Extend the server into the maintenance position.
See Extend the Server to the Maintenance
Attach an antistatic wrist strap to your wrist, and then to a metal area of the
chassis.
See Take Antistatic Measures.
Remove the server top cover.
See Remove the Server Top
Remove the Air Baffle.
Remove a Fan Module.
Remove the Fan Tray.
Remove a Half Height PCIe
Remove a Power Supply.
