To disconnect connector A:
7.
a.
b.
Remove the CMA from the rack and place it on a flat surface.
8.
Go to the front of the server and push it back into the rack.
9.
Remove the Server From the Rack
This section describes how to remove the server from the rack. For most service actions you
won't need to do this.
Caution:
The server weighs approximately 76 lbs (34 kg). A mechanical lift or two people are
required to remove the server from the rack and carry the chassis.
Always load equipment into a rack from the bottom up so that the rack does not
become top-heavy and tip over. Extend the rack anti-tilt bar to prevent the rack from
tipping during equipment installation.
Disconnect all the cables and power cords from the server.
1.
Remove the cable management arm (CMA).
2.
See
Extend the server to the maintenance position.
3.
Call Out
Description
1
Connector B release lever
Place your left arm under the CMA to support it and grasp the back end of connector
A with your left hand.
Use your right thumb to pull the connector A release lever to the right, away from the
left slide-rail (callout 1), and use your left hand to pull the connector out of the slide-
rail [1 and 2].
Call Out
Description
1
Connector A release lever
Remove the Cable Management
Preparing the Server for Component Replacement
Arm.
Chapter 2
2-17
