Remove the drive filler panel of an unpopulated slot by using your finger to pry open the
1.
panel release latch and pulling the filler out of the drive slot.
Open the latch of the new drive by pressing the release button on the drive.
2.
Insert the new drive by sliding the drive into the slot until the drive is fully seated. Then
3.
close the drive latch to lock the drive in place.
Repeat steps 1 - 3 for each new drive.
4.
For the Oracle Database Appliance X10-L, the name for these drives to the host will be
pd_02 and pd_03.
Power on each of the new drives by entering the appropriate commands from the host
5.
using the following command format:
# odaadmcli power disk on pd_##
Where ## is the number of the drive being powered on (02 and 03).
It can take a few minutes for the power-on operation to complete. Once complete, the
green OK indicators will light for the newly installed drives.
Expand the system storage to include the new drives. Type the following command from
6.
the host:
#
odaadmcli expand storage -ndisk number_of_disks
Where number_of_disks is the number of disks being added. The system will then detect
and use the new storage.
For additional information, refer to the Oracle Database Appliance Deployment and
User's Guide.

Servicing Fan Modules (CRU)

Perform tasks for servicing the fan modules and the fan tray.
Fan modules are located in the front of the server do not require you to power off the server
before servicing.
Note:
Replace filler panels with drives one at a time to ensure proper system cooling.
Caution:
Do not over-rotate the latch outwards when opening. Doing so can damage it.
Note:
Do not attempt to power on and expand storage on one new disk and then
power on and expand storage on the next new disk. Before you can expand
storage, all the new disks must be powered on with their green OK indicators lit.
Oracle Database Appliance X10 Server Hot-Pluggable Components
Chapter 3
3-5
