Remove the Server Top Cover

Remove the top cover to service components inside the server.
To service non-hot pluggable components, ensure that AC power cords are disconnected
1.
from the server power supplies.
If the release button latch is in the locked position, use a Torx T15 screwdriver to turn the
2.
release button latch clockwise to the unlocked position.
Unlatch the top cover [1].
3.
Lift up on the release button on top of the server cover. Lifting the release button slides
the server cover toward the rear of the chassis for easy removal.
Note:
An antistatic wrist strap is not included in the Accessory Kit for the server.
However, antistatic wrist straps might be included with options and
components.
Note:
Fan modules and M.2 flash SSDs are hot-pluggable and do not require AC
power cables to be disconnected from the server power supplies.
