Oracle Database Appliance X10 Service Manual page 19

Callout
4
5
6
7
8
Oracle Database Appliance X10-HA Status Indicators
Indicator/LED: Color
• 4a. Oracle Dual Port 25
Gb Ethernet Adapter,
Mellanox, SFP28 ports:
green/amber
--or--
• 4b. Oracle Quad Port
10GBase-T Adapter
RJ-45 ports: green/yellow
System locate: white
NET 0 port: green
NET MGT port: green
System service required and
OK: various
State Meaning
Oracle Dual Port 25 Gb
Ethernet Adapter, Mellanox.
Each port has one bi-colored
status LED:
• Off - No link.
• Solid green - Valid link.
• Flashing green - Link with
packet activity.
• Blinking amber (4Hz) -
Problem with the link.
Oracle Quad Port 10GBase-T
Adapter. Each of the four ports
has:
• Top activity indicator:
– Off - No activity.
– Flashing - Packet
activity.
• Bottom link indicator:
– Off - 100 Mb link.
– Green On - 10GbE
link.
– Yellow On - 1GbE
link.
This operates in the same way
as on the front panel.
10/100/1000 BASE-T Ethernet
interface.
Top right speed indicator:
• Off - 10/100BASE-T link.
• On - Green for 1000Base-
T link.
Top left link indicator:
• Off - No link or link down.
• On - Link up.
• Blinking - Packet activity.
10/100/1000 BASE-T Ethernet
management interface.
Top left speed indicator:
• Off - 10/100BASE-T link.
• On - Green for 1000Base-
T link.
Top right activity indicator:
• Off - No link or link down.
• On - Link up.
• Blinking - Packet activity.
These operate in the same
way as on the front panel.
