Oracle Database Appliance X10-HA Status Indicators
Indicator/LED: Color
Locate: white
Service Required: amber
OK: green
SAS I/O Module Ready-to-
Remove: blue
SAS I/O Module Service
Required indicator: amber
SAS I/O Module OK: green
Host SAS port Service
Required indicator: amber
Host SAS port activity
indicator: green
State Meaning
•
Off - Normal operation.
•
Fast blink - This LED
blinks to help locate the
system. Operators can
turn this indicator on and
off remotely using Oracle
ILOM.
•
Pressing this button
toggles the fast blink on or
off.
•
Off - Normal operation.
•
Steady on - A fault is
present in the storage
shelf.
•
Off - The storage shelf is
unplugged or turned off.
•
On - The storage shelf is
powered on and operating
normally.
•
Off - The I/O module has
not been prepared for
removal.
•
On - The I/O module can
be safely removed during
a hot-plug operation.
•
Off - Normal operation.
•
Steady on - A fault is
present in the SAS I/O
module.
•
Off - The I/O module is
unplugged or turned off.
•
On - The I/O module is
powered on and operating
normally.
•
Off - Normal operation.
•
Steady on - A fault is
present with the port or
connection.
•
Off - No link activity.
•
Random blinking -
Indicates host SAS link
activity.
Chapter 1
1-15
