Safety Precautions - Oracle Database Appliance X10 Service Manual

Note:
Only authorized Oracle Service personnel can service FRU components.
FRU (Service Level)
Processor and
heatsink (Cold
service)
Fan tray (Cold service) Houses the fan modules.
Disk backplane (Cold
service)
Front LED indicator
module (Cold service)
PCIe slot Flyover
cable (Cold service)
Motherboard
assembly (Cold
service)
Related Topics
•
•

Safety Precautions

For your protection, observe the following safety precautions when setting up your
equipment:
• Follow all standard cautions, warnings, and instructions marked on the equipment
and described in the Oracle Server Safety and Compliance Guide and Important
Safety Information for Oracle's Hardware Systems.
• Ensure that the voltage and frequency of your power source match the voltage
and frequency that appear on the equipment electrical rating label.
• Follow the electrostatic discharge safety practices as described in
Discharge
• Disconnect both power supply cords (if necessary) before servicing components.
Description
Processor that carries out the instructions of
the system.
Provides power and communications
connectors for storage drives.
Contains the push-button circuitry and LEDs
that are displayed on the front panel.
Supports PCIe slots 6 and 7 in the system.
Provides connectors for the DIMMs,
processors, PCIe risers, and other
components.
Safety.
Note:
Power cords must be disconnected when servicing components that
require cold service.
Chapter 2
Safety Precautions
Replacement
Instructions
Servicing Processors
Servicing the Fan Tray
Servicing the Disk
Backplane
Servicing the Front
LED Indicator Module
Servicing the PCIe
Slot Flyover Cable
(FRU)
Servicing the
Motherboard
Assembly
Electrostatic
2-4
