Oracle Database Appliance X10-HA Storage Shelf Hot Pluggable Components
Note:
Replace filler panels with drives one at a time to ensure proper
storage shelf chassis cooling.
Open the drive lever of the new drive by pressing the release button on the
b.
drive.
Slide the new drive into the drive slot [1] until it engages with the backplane
c.
connector and then close the lever to fully seat the drive and lock it into place
[2] as shown in the following figure.
Check that the drive is locked in place and flush with the other drives.
