Connect the NET MGT Cable

The SP network management port is labeled NET MGT. After the initial server configuration,
you can connect to the SP over an Ethernet network using this NET MGT port.
If your network uses a DHCP server to assign IP addresses, the DHCP server will assign an IP
address to this NET MGT port. With this IP address, you can connect to the SP using an SSH
connection. If your network does not use DHCP, this NET MGT port will not be accessible
until you configure the network settings through the SER MGT port. For instructions, see
"Assign a Static IP Address to the NET MGT Port" on page
Connect the NET MGT port to your network switch or hub using a Category 5 (or
better) cable.
See "Rear Panel Components" on page 14
The NET MGT port is not operational until you configure the network settings through
the SER MGT port as detailed in
Port" on page 68.
The NET MGT port is configured by default to retrieve network settings with DHCP and
Note -
to enable connections using SSH. You might need to modify these settings for your network.
Information related to changing these settings are in
Time".
Related Information
"Connect a Terminal or Emulator to the SER MGT Port" on page 68
■
"SER MGT Ports" on page 58
■

Connect the Ethernet Network Cables

The server has four RJ-45 network connectors labeled NET0, NET1, NET2, and NET3. Use
these ports to connect the server to the network. The Ethernet interfaces operate at 100 Mbps,
1000 Mbps, and 10000 Mbps. See
The Oracle ILOM sideband management feature enables you to access the SP using one
Note -
of these Ethernet ports. Refer to the administration guide for your server for instructions.
To achieve 1-GbE network speeds, use Category 6 (or better) cables and network devices
Note -
that support 1000BASE-T networks.
for connector locations.
"Connect a Terminal or Emulator to the SER MGT
"Powering On the Server for the First
"Rear Panel Components" on page 14
Connect the NET MGT Cable
80.
for port locations.
Connecting the Server Cables 63
