Assembling Conquest

Secure the cable to the handle using the Velcro straps. Ensure there is enough slack in the

cable that, as the handle moves up and down, it does not strain the cable or the connector.

3.2.2 Carry Harness

For convenience during data collection, the Display Unit can be carried using the optional

harness shown in Figure 3-12.

Figure 3-12: The Display Unit can be attached to the optional harness for operating the system.

The clips on the harness connect to the rings in the four corners of the Display Unit. The longer

straps go over the shoulders and the short straps go under the arms. Adjust the length of the

straps for comfort.

The Deluxe Harness allows the operator to easily mount the Display Unit at a comfortable, fixed

viewing angle for ease of operation. The harness resembles a vest which is pulled over the

body (Figure 3-13).
