Technical Specifications - Sensors & Software CONQUEST 100 User Manual

Conquest 100

15 Technical Specifications

Specifications
Sensor head size
Sensor weight
Display Unit weight (without
battery)
Battery weight
Display Unit screen
Colors
Wireless
Audio
Acquisition Rate
Battery
Charger
Display Unit input
Temperature &
Environmental
Battery Storage
Regulatory Specifications
Values
150 x 130 x 190 mm (5.84 x 5.00 x 7.38 in)
1.00 kg (2.18 lbs)
2.83kg (6.24 lbs)
0.48 kg (1.05 lbs)
8.0" high-visibility, sunlight-readable diagonal LCD display with
touchscreen
Adjustable backlighting
1000 NIT and 800:1 contrast ratio
24 total color palettes (8 color palettes with 3 contrast levels per
palette)
Integrated modules:
Wi-Fi (IEEE 802.11 b,g,n)
GPS/GLONASS
Built-in speaker - 85dBA speaker w/volume control
Bluetooth connectivity
100,000 samples/s
Lithium Battery pack
Battery Life: 4-6 hours
Battery Capacity: 9 Ah
Built-in power management features to conserve battery power and
preserve data integrity
Built-in charger with status indicator
Universal AC mains charger input: 100-240V
Output: 18V, 4.45A, 80W Max
10-24V , 4A maximum
Ruggedized, environmentally sealed unit and connections
Ingress protection (IP) rating: DVL-500 is rated to IP65 under IEC
60529
Relative Humidity operation (non-condensing): 10 – 90%
DVL-500 operating temperature range: -40 to 50°C
Use battery charger/AC adapter between 0 and 35°C.
Operation on battery is possible below -20°C but battery endurance
will be limited. Do not use touch screen below -20°C.
Recommended conditions for battery storage are -20 to 25°C.
Maximum temperature range for battery storage is -20 to 60°C.
Extended storage above 40°C could degrade battery performance
and life.
EMC-FCC, CE, IC
Safety-TUV, CE
117
Technical Specifications
, 2A, 50/60Hz
