Conquest 100
1

Overview

Conquest 100 is an integrated ground penetrating radar (GPR) system specifically designed to
meet the needs of the concrete inspection industry. The system consists of the Display Unit,
Sensor Head, cable, survey grids, battery and battery charger/AC adapter. Optional items
include a resizable handle for the Sensor Head, harness, Bluetooth remote, extra battery and a
desktop battery charger.
The PCD (Power Cable Detector) feature uses an additional sensor built into the Conquest
Sensor Head to detect and image current-carrying cables inside or beneath the concrete. The
PCD data are collected at the same time as the GPR data so there is no additional effort
required by the operator.
Conquest 100 is also available in an Enhanced configuration. The chart below summarizes the
differences between the two configurations:
Criteria
How is data
saved?
How much data
can be saved?
File organization
PC-based data
display
This manual references embedded software version V2 R3. This number can be found from the
swipe down menu (Section
Online training videos for the Conquest 100 can be found on Sensors & Software's
website at:
https://www.sensoft.ca/training-events/training/conquest-100/
login & password to access this)
Conquest 100
Screenshots (.JPG)
1 Project with:
•
20 grids
•
200 lines
•
1000 screenshots
Lines and Grids
Any .JPG viewing software
4.1).
Conquest 100 Enhanced
Screenshots (.JPG) and .GPZ files
20 Projects each with:
•
20 grids
•
200 lines
•
1000 screenshots
Projects containing Lines, Grids &
Screenshots
Data can be opened in
EKKO_Project
(Note: you will need to setup a
5
Overview
