Conquest 100
Assembling Conquest
Power button
and light
Figure 3-17: The Display Unit
3.3.3 USB port
The Display Unit saves data to internal memory. Data can be transferred to a PC for post
processing and report writing.
USB Port
Figure 3-18: The Display Unit has a USB port for data export.
To transfer data from the Display Unit to a PC, insert a USB 2.0-compatible drive (memory stick)
into the USB port on the right side of the Display Unit (Figure 3-18). Once the USB drive is
recognized, the user is prompted to confirm they would like to copy the data.
The USB port is also used to update the Display Unit software
(Section
13.5). When a USB
drive with a new embedded software installation is inserted, the user is prompted to confirm
they would like to update the software.
29
