Conquest 100
When the system is powered by battery, the light on the front of the Display Unit will illuminate
green as the system boots up. Once it boots up, the color of the light will depend on the current
battery charge:
When the system is powered by the AC Adapter, the light on the front of the Display Unit will
illuminate red at first and then orange as the system boots up and remain orange until the
system is powered down.
As the Sensor Head is initialized, it will beep and the lights on the Sensor Head keypad will flash
several times. When the main menu appears on the Display Unit, the system is powered up
and ready to collect data.
There are certain conditions when the user will be forced to do a Sensor Calibration on bootup.
These are:
•
A different Sensor Head is connected to the Display Unit
•
After an embedded software update
•
User resets to factory defaults
The procedure for the Sensor Calibration is described in
The Sensor head MUST be connected to the Display Unit for the Sensor Calibration. Do NOT
connect the Sensor Head after system power up has begun. Power down the system BEFORE
connecting the Sensor Head cable; otherwise damage to the Sensor Head could result.

3.5.2 Powering Down

The system can be powered down at any time by pressing the red button on the front of the
Display Unit. The user is prompted to confirm they would like to power down the system.
•
100% to 20% = green
•
20% to 10% = orange
•
10% to 0% = red
(Section 5.1.12)
Section 5.2.7.
32
Assembling Conquest
