Parameter Group 1-** Motor Details - Danfoss VLT MCD 600 Operating Manual

VLT® Soft Starter MCD 600
Operating Guide
Parameter group number
36-2
36-3
36-4
36-5
36-6
36-7
36-8
36-9
36-10
40
40-1
40-2
40-3
40-4
40-5

10.5 Parameter Group 1-** Motor Details

Table 30: 1-1 - Command Source
Option Function
Selects the command source for controlling the soft starter.
* Digital input The soft starter accepts start and stop commands from the digital inputs.
Network The soft starter accepts start and stop commands from the communication expansion card.
Remote LCP The soft starter accepts start and stop commands from the remote LCP.
Clock
The soft starter accepts starts and stops as scheduled in parameters 4-1 to 4-24.
Smart card The soft starter accepts start and stop commands from the smart card.
Smart card + The soft starter accepts start commands from the smart card if they are within the operating schedule set
clock
in parameters 4-1 to 4-24. A stop command from the smart card is accepted regardless of the schedule.
Timer After a start signal is received, the soft starter starts and stops the motor according to the timers set in
parameter 4-2 Run Time and parameter 4-3 Stopped Time.
Table 31: 1-2 Motor Full Load Current
Range Function
Model dependent Matches the soft starter to the FLC of the motor. Set to the FLC rating shown on the motor nameplate.
82 | Danfoss A/S © 2020.12
Parameter group name
Flow Sensor
Depth Sensor
High Pressure
Low Pressure
High Flow
Low Flow
Flow Switch
Well Depth
RTD/PT100 B
Ground Fault
Ground Fault Level
Ground Fault Delay
Ground Fault Trip Active
Ground Fault Action
Ground Fault CT Ratio
Programmable Parameters
Default setting
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
Soft Trip and Log
0 A
00:01 (mm:ss)
Operating only
Soft Trip and Log
1000:1
