VLT® Soft Starter MCD 600
Operating Guide

10 Programmable Parameters

10.1 Main Menu

Use the Main Menu to view and change programmable parameters that control how the soft starter operates.
To open the Main Menu, press [Menu/Store], scroll to Main Menu, and press [Menu/Store] again.
Parameters for smart card functions are only visible in the parameter list if the smart card is installed.

10.2 Changing Parameter Values

Procedure
1. Scroll to the parameter in the Main Menu.
2.
Press [Menu/Store] to enter edit mode.
3. Press [▵] or [▿] to change parameter settings.
Pressing [▵] or [▿] once increases or decreases the value by 1 unit. If the key is held for longer than 5 s, the value increases
or decreases at a faster rate.
- Press [Store] to save changes. The setting shown on the display is saved and the LCP returns to the parameter list.
- Press [Back] to cancel changes. The LCP asks for confirmation, then returns to the parameter list without saving the
changes.

10.3 Adjustment Lock

Use parameter 10-7 Adjustment Lock to prevent users from changing parameter settings.
If a user attempts to change a parameter value when the adjustment lock is active, the following error is shown: Access Denied. Adj
Lock is On.

10.4 Parameter List

Table 29: Parameter List
Parameter group number
1
1-1
1-2
1-3
1-4
1-5
1-6
1-7
2
2-1
2-2
2-3
2-4
2-5
74 | Danfoss A/S © 2020.12
N O T I C E
Parameter group name
Motor Details
Command Source
Motor Full Load Current
Motor kW
Locked Rotor Time
Locked Rotor Current
Motor Service Factor
Reserved
Motor Start/Stop
Start Mode
Start Ramp Time
Initial Current
Current Limit
Adaptive Start Profile
Programmable Parameters
Default setting
Digital Input
Model dependent
0 kW
00:10 (mm:ss)
600%
105%
–
Constant Current
00:10 (mm:ss)
200%
350%
Constant Acceleration
