VLT® Soft Starter MCD 600
Operating Guide
Option
Custom Message

10.12 Parameter Group 8-** Relay Outputs

Table 147: 8-1 - Relay A Function
Option Function
Selects the function of Relay A.
Relay A is a changeover relay.
Off Relay A is not used.
Ready The relay is closed when the soft starter is in Ready state.
* Run The Run output closes when the soft start is complete (when the starting current drops below 120% of
the programmed motor full load current). The output remains closed until the beginning of a stop (ei-
ther soft stop or coast to stop).
Warning The relay closes when the soft starter issues a warning.
Trip The relay closes when the starter trips.
Low Current Flag
The relay closes when the low current flag activates while the motor is running (see parameter 8-7 Low
Current Flag).
High Current Flag
The relay closes when the high current flag activates while the motor is running (see parameter 8-8 High
Current Flag).
Motor Tempera-
The relay closes when the motor temperature flag activates (see parameter 8-9 Motor Temperature Flag).
ture Flag
Soft Brake Relay The relay closes when the soft starter receives a stop signal, and remains closed until the end of soft
brake.
Reversing Contac- The relay controls an external contactor, for reverse operation.
tor
Trip Failsafe The relay closes when control power is applied. The relay opens if the soft starter trips or if control power
is lost.
Table 148: 8-2 - Relay A On Delay
Range
* 0 s 0:00–5:00 (minutes:seconds)
Table 149: 8-3 - Relay A Off Delay
Range
* 0 s 0:00–5:00 (minutes:seconds)
Table 150: 8-4 - Relay B Function
Option
Off
104 | Danfoss A/S © 2020.12
Function
Function
Sets the delay for changing the state of Relay A.
Function
Sets the delay for changing the state of Relay A.
Function
Selects the function of Relay B (normally open).
See parameter 8-1 Relay A Function for details.
Programmable Parameters
AQ262141844215en-000401 / 175R1174
