VLT® Soft Starter MCD 600
Operating Guide
Table 50: 2-14 - Start Delay
Range
* 0 s 0:00–60:00 (minutes:seconds)
Table 51: 2-15 - DC Brake Torque
Range
* 20% 20–100%
Table 52: 2-16 - DC Brake Time
Range
* 1 s 0:01–0:30 (minutes:seconds)
Table 53: 2-17- Brake Current Limit
Range
* 250% 100–600% FLC
Table 54: 2-18 - Soft Brake Delay
Range Function
*400 ms 400–2000 Sets the time which the soft starter waits after a stop signal is received before it begins to supply brak-
ms ing current to the motor. Set to allow time for K1 and K2 to switch.

10.7 Parameter Group 3-** Motor Start/Stop-2

The parameters in this group control the operation of the secondary configuration of the motor. Use the programmable input to
select the active motor set.
See 9.14 Secondary Motor Set
Table 55: 3-1 - Motor Full Load Current-2
Range
Model dependent
Table 56: 3-2 - Motor kW-2
Range
* 0 0–9999 kW
Table 57: 3-3 - Start Mode-2
Option
* Constant Current
Adaptive Control
Table 58: 3-4 - Start Ramp Time-2
Range
*10 s 0:01–3:00 (minutes:sec-
onds)
86 | Danfoss A/S © 2020.12
Function
Sets a delay after the soft starter receives a start command before it starts the motor.
Function
Sets the amount of brake torque the soft starter uses to slow the motor.
Function
Sets the duration for DC injection during a braking stop.
Function
Sets the current limit for soft brake.
for more details.
Function
Sets the secondary motor's full load current.
Function
Sets the running power of the secondary motor in kW.
Function
Sets the total start time for an adaptive control start or the ramp time for current ramp starting
(from the initial current to the current limit).
Function
Selects the soft start mode.
Programmable Parameters
