VLT® Soft Starter MCD 600
Operating Guide
6.7 USB Save & Load
The USB Save & Load menu allows:
•
Saving parameter settings and all event log entries to an external file (CSV format).
•
Saving parameter settings to an external file (proprietary format).
•
Loading parameter settings from a previously saved external file.
•
Loading custom messages to show on the LCP when a programmable input is active.
The VLT® Soft Starter MCD 600 supports FAT32 file systems. The MCD 600 USB functions are not compatible with NTFS file sys-
tems.
6.7.1 Save and Load Procedure
Procedure
1.
Connect the external drive to the USB port.
2.
Press [Menu/Store] and select Setup Tools.
3.
Scroll to USB Save & Load and press [Menu/Store].
USB Save & Load
Save Params and Logs
Save Master Params
Load Master Params
4.
Scroll to the required function and press [Menu/Store].
5.
At the confirmation prompt, select Yes to confirm or No to cancel.
6.
Press [Menu/Store] to proceed.
When the action has been completed, the screen briefly shows a confirmation message, then returns to the previous menu level.
6.7.2 File Locations and Formats
Save parameters and logs
The soft starter creates a directory at the top level of the USB drive, named with the soft starter serial number. The event log and
parameter settings are saved as individual CSV files, and the soft starter's software and system information are saved to a text file.
Save master parameters
The soft starter creates a file called Master_Parameters.par in the top level of the USB drive.
Load master parameters
The soft starter loads the file Master_Parameters.par from the top level of the USB drive. The file can be created or edited using VLT®
Motion Control Tool MCT 10. Download the MCT 10 tool from
Load custom message
The soft starter loads the files Custom_Message_A.txt and Custom_Message_B.txt from the top level of the USB drive.
50 | Danfoss A/S © 2020.12
N O T I C E
www.danfoss.com
under the sections Service and support/Downloads.
Set-up Tools
AQ262141844215en-000401 / 175R1174
