6.11 Analog I/O State

The topline of the screen shows the state of the motor thermistor input. The bottom line of the screen shows the value of the ana-
log output.
Analog I/O State
Thermistor: 0
4-20 mA Output: 04.0 mA
Illustration 22: Analog I/O Status Screen
Thermistor input
S
H
C
O
6.12 Serial Number & Rating
The top line of the screen shows the product name.
The middle line shows the unit's serial number.
The bottom line of the screen shows the model number.
Serial Number & Rating
MCD 600
123456-123
0410-T5-S1-CV2
Illustration 23: Serial Number & Rating Screen

6.13 Software Versions

The software version screen reports the version of each software component of the soft starter:
• User interface.
• Motor control.
• Remote LCP (if connected).
• Parameter list.
• Bootloader.
• Expansion card (if fitted).
Updated software, including alternative languages, can be loaded into the soft starter via the USB port if required. Contact the
local supplier for further information.

6.14 Thermistor Reset

The thermistor input is disabled by default, but activates automatically when a thermistor is detected. If thermistors have previously
been connected to the soft starter but are no longer required, use the thermistor reset function to disable the thermistor.
Danfoss A/S © 2020.12
Short
Hot
Cold
Open
